| Microcontroller | AT91SAM3X8E | |
| Operating Voltage | 3.3V | |
| Input Voltage (recommended) | 7-12V | |
| Input Voltage (limits) | 6-16V | |
| Digital I/O Pins | 54 (of which 12 provide PWM output) | |
| Analog Input Pins | 12 | |
| Analog Outputs Pins | 2 (DAC) | |
| Total DC Output Current on all I/O lines | 130 mA | |
| DC Current for 3.3V Pin | 800 mA | |
| DC Current for 5V Pin | 800 mA | |
| Flash Memory | 512 KB all available for the user applications | |
| SRAM | 96 KB (two banks: 64KB and 32KB) | |
| Clock Speed | 84 MHz |
Microcontroller AT91SAM3X8E
Operating Voltage 3.3V
Input Voltage (recommended) 7-12V
Input Voltage (limits) 6-16V
Digital I/O Pins 54 (of which 12 provide PWM output)
Analog Input Pins 12
Analog Outputs Pins 2 (DAC)
Total DC Output Current on all I/O lines 130 mA
DC Current for 3.3V Pin 800 mA
DC Current for 5V Pin 800 mA
Flash Memory 512 KB all available for the user applications
SRAM 96 KB (two banks: 64KB and 32KB)
Clock Speed 84 MHz
